AVIAO TF MINI CONTENDER EP ARF TOPA1025

Ref: 85205

Estoque: Indisponível

R$ 1.278,42

Comprar

Product Details

Overview

The original Top Flite Contender made its debut over 40 years ago. Thousands of pilots have honed their skills flying this classic aerobat. An ultra-thick airfoil allows an ultra-wide flight envelope, so it’s just as adept at slow and steady flight as it is wild, full-throttle aerobatics.

Features

Construction: Balsa and ply
Wing: One-piece
Aileron Control: Dual servo, allows for flaperon mixing and precise control during aerobatics
Covering: Top Flite Monokote
Canopy: Clear ABS, pilot figure shown in photos is not included
Landing Gear: Prebent wire with 1.3" (34mm) diameter foam wheels, steerable nose gear
Spinner: White plastic 1.5" (35.7mm) diameter

Needed to Complete

Radio: At least four channels
Servos: Four micro
Y-Harness: One 6" (152mm) for aileron servos
Servo Extensions: Four 6" (152mm)
Motor: .10 size brushless outrunner
Electronic Speed Control: 35A
LiPo Battery: 11.1V (3S) 1800-2200mAh
Battery Charger: For selected LiPo battery
Propeller: 9x6 electric
Building and field equipment

What's in the box?

(1) Mini Contender EP ARF 36" with prebuilt wing, fuselage and tail sections, landing gear, spinner and decals
(1) User Manual

Specifications

Wingspan: 36" (915mm)
Wing Area: 329 sq in (21.2 sq dm)
Wing Loading: 11.8-13.1 oz/sq ft (36-40 g/sq dm)
Weight: 27-30oz (465-850g)
Length: 34.5" (875mm)
Center of Gravity (CG): 2-5/16" (59mm) back from the leading edge of the wing at the fuselage side
Control Throws: Low Rate / High Rate
Elevator: 1/4" (6mm) 7° 3/8" (10mm) 11°
Rudder: 3/4" (19mm) 14° 3/4" (19mm) 14°
Ailerons : 5/8" (16mm) 25° 3/8" (10mm) 14°
