MOTOR DL ENGINE 70CC HYBRID UAV(DRONE) DLE70HD

MOTOR DL ENGINE 70CC HYBRID UAV(DRONE) DLE70HD

MOTOR DL ENGINE 70CC HYBRID UAV(DRONE) DLE70HD

MOTOR DL ENGINE 70CC HYBRID UAV(DRONE) DLE70HD

MOTOR DL ENGINE 70CC HYBRID UAV(DRONE) DLE70HD

Ref: 405652

Estoque: Disponível

R$ 25.739,91

Comprar

DLE70HD hybrid engine, which was launched in March 2021, is a double cylinder two-stroke water-cooled piston engine with efficient water cooling and heat dissipation, providing a more stable working mode for the engine. The engine is designed to provide power for aircraft. This power package is an independent and complete closed-loop system. It has nothing to do with the use and adjustment of remote control and flight control.

Generator parameters:

Three phase permanent magnet generator

Voltage: ac50v to dc50v

Frequency: non constant frequency type, which changes with the engine speed

Engine parameters:

Horizontal opposed double cylinder water cooling

Displacement : 70cm3

Cylinder bore × trip：38.5mm×30mm

Power 7hp/8200 RPM power: 4.2kW (0 altitude)

Idle speed: 5000-6000 rpm

Engine weight: 4.8kg

Weight of cooling system; 2kg (including 800ml coolant)
