MOTOR DL ENGINE 128HD CC HYBRID UAV(DRONE) DLE128HD

MOTOR DL ENGINE 128HD CC HYBRID UAV(DRONE) DLE128HD

Ref: 405645

Estoque: Indisponível

R$ 44.054,92

Comprar

DLE128HD Hybrid UAV Engine，Launched in March, 2020, the dual cylinder two-stroke water-cooled piston engine, with efficient water cooling and heat dissipation, provides a more stable working mode for the engine. The engine is designed to provide power for aircraft. This power package is an independent and complete closed-loop system. It has nothing to do with the use and adjustment of remote control and flight control.

Generator parameters:

Three phase permanent magnet generator

Voltage: ac50v to dc50v

Frequency: non constant frequency type, which changes with the engine speed

Engine parameters:

Horizontal opposed double cylinder water cooling

Displacement : 128cm3

Cylinder bore × Stroke: 47mm × 35mm

Power 12hp/8300 RPM: 7.4kw (0 altitude)

Idle speed: 3500-6000 rpm

Engine weight: 6.2kg

Weight of cooling system; 2kg (including 800ml coolant)
