IMAX CHARGER PC1260 12S DUAL CHARGER SK-100138-04

Dual Channel 12S Lithium Battery Charger

SkyRC PC1260 is a dual channel 12S LiPo charger for industrial application drones. It is reliable, safe and easy to operate while with comprehensive functionality, like battery voltage meter, internal resistance meter, LiHV charging mode, also the time saving synchronization mode.

Sophisticated industrial and mechanical design, optimizes the space. Selecting components from well-known brands, guarantees stable quality and durability.

Using advanced 32bits high speed CPU from STMicroelectronics, processing capability improves 20 times.

High Frequency Capacitor

• Using high spec large capacitor, ensures the charger can work properly for longer period of time.

• Active PFC uses a circuitry to correct the amount of power drawn to obtain the best ratio of power factor, achieving high efficiency, 93%. Which makes the product more stable and reduces the interferences to the power grid.

Dual Channel 12S Lithium Battery Charger

• SkyRC PC1260 is a dual channel 12S LiPo charger for industrial application drones. It is reliable, safe and easy to operate while with comprehensive functionality, like battery voltage meter, internal resistance meter, LiHV charging mode, also the time saving synchronization mode.

• Sophisticated industrial and mechanical design, optimizes the space.

• Selecting components from well-known brands, guarantees stable quality and durability.

• Using advanced 32bits high speed CPU from STMicroelectronics, processing capability improves 20 times.

SPECIFICATION:

• Input Voltage - 100-240V
• Output Power - 1260W (630W x 2)
• Discharge Power - 100W (50W x 2)
• Charge Current - 1.0-12.0A x 2
• Balance Current - 1.5A
• Battery Type - LiPo/LiHV
• Battery Cell Count - 12S
• Working Mode
• Balance Charge Mode
• Storage Mode
• Charge Mode
• Net Weight - 4.88kg
• Size - 272x202x118.6mm
