ALIGN APS-M MULTICOPTER COMPLET HEGAPS04

Ref: 215466
Estoque: Disponível
R$ 1.593,99
Comprar

WITH DUAL GPS SENSOR

Product:
Product:
Package:
Instruction: Specification:
•Suitable for M480L / M690L or 4 rotors +, 4 rotors X, 6 rotors +, 6 rotors X...Multicopters
Brand new APS-M multicopter auto pilot system with superior performance through cutting edge IT technologies, utilizing high precision sensors and modern system control subroutines. Support quad(4), hex(6), and octo(8) rotors. Flight modes include attitude, GPS speed, GPS angular, intelligent, and manual. In addition, it features failsafe auto return home, low voltage failsafe (through LED indicator and auto Return Home), OSD signal output, gimbal control, and Point of Interest(POI) function.

•Compatible with PC and Bluetooth interface, could be easily adjust flight parameter and update firmware at any time.
Brand new APS-M multirotor auto-pilot system with higher performance, precision sensors and superior reliability platform.
•Equipped with automatic return home function with remote activation ability from R/C transmitter. When RC transmitter signal is lost, multicopter will automatically fly back to home position.
•APS-M provides 3 intelligent flight modes: CFO, HCL, and POI.
•Provides real-time OSD flight data output function.
•RoHS certified.
•Compatible with PC and Bluetooth interface, could be easily adjust flight parameter and update firmware at any time.
•Also fully support with Futaba, Spectrum and JR S. BUS/S.BUS and DSM2/DSMX/DSMJ/DMSS system.		 •Input Voltage:DC4.5V~8.4V.
•Operating Current Consumption:<250mA@ 4.8V.
•Operating Frequency:400Hz
•Operating Temperature:-20° ~ 65°C(-4° ~ 149 °F)
•Hovering Precision (Depending on Satellite Status):Horizontal ±1m, Vertical ±1m
•Highest Flight Speed:Horizontal 15m/sec, Vertical 6m/sec
•Maximum Altitude Restriction:700m(1640ft) above the takeoff point
•Maximum Angular Speed:ALE 115° /sec, ELE 115° /sec, RUD 145° /sec
•Maximum Tilting Angle:30 degrees
•Supports External Peripherals:G2 / G3 Gimbal、OSD+FPV Video Transmitter
•Supports Multicopter Configurations: 4 rotors +, 4 rotors X, 6 rotors +, 6 rotors X, 8 rotors +, 8 rotors X
•Dimension / Weight: 49x34.3x20mm / 21.27g
Content:
•APS-M Flight Control System x 1
•APS-M Signal Wire Set ×1 (around 280mm)x 1
•APS-M Signal Wire x 3
•External Status LED x 1
•GPS Sensor x 1
•USB Cable Set x 1
•External Status LED Sided Mounting Tape x 2
•APS-M Sided Mounting Tape x 2
•GPS Sided Mounting Tape x 2
•APS-M Automatic Flight System Download:(Click)
